Caston III Digital Scales
- Battery Operated with low battery indication
- Rechargeable battery pack
- Spare battery pack and charger included as standard
- Remote control included as standard
- On, Off, Zero, Tare and Hold (manual or automatic) functions
- Easy to read 1.5" LED Display
- Auto span adjustment
- Auto Zero Tracking
- Environmentally sealed to IP 67 standards
|
|
| Model |
5-THD |
10-THD |
15-THD |
20-THD |
30-THD |
50-THD |
| Price |
 |
|
|
|
|
|
| Capacity |
10000 x 5 lb
5000 kg x 2 kg |
20000 x 10 lb
10000 x 5 kg |
30000 x 10 lb
15000 x 5 kg |
40000 x 20 lb
20000 X 10 kg |
60000 x 20 lb
30000 X 10 kg |
100,000 x 50 lb
50,000 x 20 kg |
| Shipping Wt. |
98 lbs |
153 lbs |
158 lbs |
240 lbs |
710 lbs |
1050 lbs |
| Maximum Tare |
Full Tare |
| Accuracy |
Plus or minus 0.1% of applied load |
| Overload |
Safety: 150% of rated capacity
Ultimate: 300% of rated capacity |
| Housing |
Alodined cast aluminum Double O-ring gasket NEMA 4 IP 65 |
| Hook, Eye, Shackles |
Crosby or equivalent |
| Display Type |
LED / 6 Digit (1.5 inch) |
| Calibration |
Manual |
| Operating Power |
DC 12V |
| Operating Time |
14 - 24 hours |
| Power Source |
AC 120V, 50/60 Hz |
| Display Designators |
Zero, Tare, Hold, Batt |
| Power Consumption |
1.2W |
| Operating Temp |
-10oC ~ 40oC / 14oF ~ 104oF |
Caston
III BlueTooth Digital Scales
- Battery Operated w/Low Battery Indicator
- Rechargeable Battery Pack
- Spare Battery Pack and Charger Included
- Easy to Read 1.5? Display
- On, Off, Zero, Tare, and Hold (Manual or Automatic) Functions
- Auto Span Adjustment
- Auto Zero Tracking
- Includes - Wireless Remote for Caston III Models - TW-100 Bluetooth Remote Control for Caston III BT Model - Remote Base includes RS-232C - Cradle included with 60K & 100K Models
|
|
- 10K, 20K, 30K, 40K, 60K, & 100K Capacities
- Bluetooth Wireless Remote Control (TW100)
- Battery Operated (Rechargeable)
- Spare Battery Pack & Charger Included
- Easy to Read 1.5" LED Display
- On, Off, Zero, Tare, & Hold Buttons
- Auto Span Adjustment
- Auto Zero Tracking
- Bluetooth Oprating Range over 350ft
|
 |
Specs
| Model |
5-THD-BT |
10-THD-BT |
15-THD-BT |
20-THD-BT |
30-THD-BT |
50-THD-BT |
| Price |
|
|
|
|
|
|
| Capacity |
10000 x 2 lb
5000 kg x 1 kg |
20000 x 5 lb
10000 x 2 kg |
30000 x 10 lb
15000 x 5 kg |
40000 x 20 lb
20000 X 10 kg |
60000 x 20 lb
30000 X 10 kg |
100,000 x 50 lb
50,000 x 20 kg |
| Shipping Wt. |
98 lbs |
153 lbs |
158 lbs |
240 lbs |
710 lbs |
1050 lbs |
| Maximum Tare |
Full Tare |
| Accuracy |
Plus or minus 0.1% of applied load |
| Overload |
Safety: 150% of rated capacity
Ultimate: 300% of rated capacity |
| Housing |
Alodined cast aluminum Double O-ring gasket NEMA 4 IP 65 |
| Hook, Eye, Shackles |
Crosby or equivalent |
| Display Type |
LED / 6 Digit (1.5 inch) |
| Frequency (BT) |
2.4 Ghz |
| Remote Distance (BT) |
Up to 350 ft / 106.7 m |
| Channels (BT) |
Up to 79 separate channels |
| Calibration |
Manual |
| Operating Power |
DC 12V |
| Operating Time |
14 - 24 hours |
| Power Source |
AC 120V, 50/60 Hz |
| Display Designators |
Zero, Tare, Hold, Batt |
| Power Consumption |
1.2W |
| Operating Temp |
-10oC ~ 40oC / 14oF ~ 104oF |
|
