Imada I-Series Non-Impact Torque Testers for Power Drivers & Wrenches

i-8 (7 lbf-in) ,i-80 (70 lbf-in) CD-150M (130 lbf-in) DI-11 (174 lbf-in) Specifications Chart

Imada I-Series Non-Impact Torque Testers for Power Drivers & Wrenches Cedar Select i-8 - i-80 - CD-150M - DI-11 - Imada SW-1SV-USB Torque Data Acquisition Software, add Imada SC-2 Non Impact Torque Testers 100 lbf-in, Cube Adapter, add Shipping Wt: 10 lbs. All Imada instruments have special price incentives. Please phone us at 800-832-0055 for the best pricing on Imada gauges.

Imada’s digital torque tester is ideal for calibrating power screwdrivers with torque control. It features peak mode to capture the peak torque achieved during a test, real time mode to display torque transients, and peak down mode to capture critical first peak value. Standard 3/8 inch drive is good for checking torque wrenches but not impact wrenches. All digital torque testers are sold in kit form complete with tester, hard carrying case, 2 smart driver adapters and AC charger/adapter. A calibration kit is also available.

Imada�s digital torque tester is ideal for calibrating power screwdrivers with a torque control clutch. It features peak mode to capture the peak torque achieved during a test, real time mode to display torque transients, and peak down mode to capture critical first peak value.

Standard 3/8" drive is good for checking torque wrenches but not impact wrenches.

All digital torque testers are sold in kit form complete with tester, hard carrying case, 2 smart driver adapters and AC charger/adapter.

• Programmable High/Low setpoints with audible beep for uniform torque tightening or GO/NO GO testing
• Peak, Real Time and Peak Down measuring modes (selectable)
• Selectable units lbf-in, Kgf-cm, N-cm and N-m
• USB data output (peak data only)
• Statistics: number of data, Max, Min, Avg
• Measure both clockwise and counterclockwise
• Heavy-duty metal construction
• Runs on internal NiCad batteries or AC adapter n 3/8" drive for socket wrenches
• 2 - driver adapters included: i-8 & i-80 come with smart adapters, CD-150 comes with spring adapters

Note: Do not use with impact or air tools (See the DI-1M impact wrench torque tester).
Smart driver adapters simulate screw tightening, eliminating the need for reversing the power driver which is required for conventional driver adapters

Model	Capacity (Resolution)
	lb-in	kg-cm	N-cm	N-m	Price
i-8	0.020 - 6.970 (0.001 lb-in)	0.020 - 8.000 (0.001 kg-cm)	0.20 - 78.60 (0.01 N-cm)	-
i-80	0.20 - 69.70 (0.01 lb-in)	0.20 - 80.00 (0.01 kg-cm)	2.0 - 786.0 (0.1 N-cm)	0.020 - 7.860 (0.001 N-m)
CD-150M	1.0 - 130.0 (0.1 lb-in)	1.0 - 150.0 (0.1 kg-cm)	1.0 - 1500 (1 N-cm)	0.10 - 15.00 (0.01 N-m)
DI-11	1.0 - 174.0 (0.1 lb-in)	1.0 - 200.0 (0.1 kg-cm)	-	0.10 - 20.00 (0.01 N-m)

Standard Driver Adapters (2 included with tester)

	i-8		i-80		CD-150M		DI-11
Adapter	Smart Adapters				Spring Adapters
Model	OW-025E	OW-10E	OW-20E	OW-60E	SJ-50E	SJ-100E	SJ-50E	SJ-200E
Price								Call
Range lb-in	2	9	18	52	8-50	50-130	8-50	50-175
Mechanical life	10000 hrs	8000 hrs	5000 hrs	5000 hrs	2500 times	2500 times	2500 times	2500 times
Screw on top	6-32	6-32	8-32	1/4-20	5/16-18	3/8-16	5/16-18	3/8-16
Plug to socket	3/8 inch square x 5/32 inch (20 mm square x 4 mm)
