Specifications
| Model |
UV5
30254725 |
UV5Bio
30254728 |
UV5Nano
30254729 |
UV7
30254726 |
| Wavelength Range (nm) |
190 nm - 1,100 nm |
190 nm - 1,100 nm |
190 nm - 1,100 nm |
190 nm - 1,100 nm |
| Photometric accuracy (K2Cr2O7) |
±0.005 A |
±0.005 A |
±0.006 A |
±0.005 A |
| Wavelength accuracy |
±0.9 nm |
±0.9 nm |
±0.9 nm |
±0.5 nm |
| Resolution (Toluene in hexane) |
>1.5 |
>1.5 |
>1.5 |
>1.9 |
| Stray light (KCl, 198nm) |
>2 |
>2 |
>1.7 |
>2.3 |
| Compatibility with LabX Software |
Yes |
Yes |
Yes |
Yes |
| Options |
CuvetteChanger, Fingerprint Reader, Cuvettes, FillPalMini, Printer, LabX PC Software, CertiRef, Barcode Reader |
CuvetteChanger, Fingerprint Reader, Cuvettes, Handheld barcode scanner, Printer USB-P25, FillPalMini, LabX PC Software, CertiRef |
Fingerprint Reader, Cuvettes, Handheld barcode scanner, USB-P25 printer, FillPalMini, LabX PC Software |
CuvetteChanger, Fingerprint Reader, Cuvettes, Handheld barcode scanner, Printer USB-P25, FillPalMini, LinSet, LabX PC Software, CertiRef |
| Shortcuts per user |
24 |
| Max. number of methods |
50 |
100 |
| Pharmacopeia compliant |
- |
No |
No |
Yes |
| Kinetic Measurements |
- |
Yes |
Yes |
- |
| User Identification |
- |
Yes |
Yes |
Yes |
| Micro-volume measurements |
- |
No |
YES |
- |
| Bio applications |
- |
Yes |
Yes |
- |
| Languages |
English, Italian, French, Russian, Portuguese, Chinese, German, Spanish, Japanese |
| Minimal Scan time |
- |
1 s |
1 s |
1 s |
| Display |
7 inch QVGA Color TFT touch sensitive screen |
| Displayed Resolution |
800x400 |
| Dimensions (HxWxD) |
8.98 in x 8.19 in x 10.04 in (228 mm x 208 mm x 255 mm) |
| Optics |
Array |
- |
Array |
| Light Source |
Xenon flash lamp |
- |
Xenon flash lamp |
| Application |
Water, Color, Scan, Quant |
Water, Kinetic, Color, Bio, Scan, Quant |
- |
Water, Kinetic, Pharma, Color, Scan, Quant |
| Weight (incl. Terminal) |
4.25 kg |
4.25 kg |
7.2 kg |
6.4 kg |
| Cuvette Changer |
No |
Yes |
- |
|
