Model with US Plug |
193155 |
207354 |
Model with EU Plug |
193156 |
207355 |
Model with UK Plug |
207348 |
207356 |
Model with AUS Plug |
207349 |
207357 |
Model with 9-36 VDC |
193157 |
- |
With External RJ45 Connector (IP66) |
- |
YES |
RATING/MATERIAL |
IP69 (IP66 with RJ45 option) AISI 304 Stainless Steel |
Legal For Trade |
NTEP CC 19-021, Class III/IIIL, 10,000d Measurement Canada AM-6121, Class III/IIIHD, 10,000d OIML |
POWER |
Line Voltage: 100-240 VAC, 50-60Hz Optional: 9-23 VDC |
POWER CONSUMPTION |
~3.2W (AC) with one 350 ohm load cell, 15W max; 4W with 4-350 ohm load cells or 8-700 ohm load cells |
EXCITATION VOLTAGE |
10 VDC (± 5 VDC), 8 x 350 ohm or 16 x 700 ohm load cells |
ANALOG SIGNAL INPUT RANGE |
-5 mV to +70 mV |
ANALOG SIGNAL SENSITIVITY |
0.3 µV/graduation minimum 1 µV/graduation recommended |
A/D SAMPLE RATE |
6.25-120 Hz, software selectable |
RESOLUTION |
Internal: 8,000,000 counts Display: 1,000,000 |
SYSTEM LINEARITY / PI RATING |
Within 0.01% full scale |
DIGITAL I/O |
Four configurable I/O - 5V logic |
COMMUNICATION PORTS |
Two RS-232 (three-wire) RS-485/422 (two-wire or four-wire) Micro USB (device) Ethernet TCP/IP (10/100) Wi-Fi Bluetooth® |
STATUS ANNUNCIATORS |
Zero, Gross/Net, Tare, Wi-Fi, Bluetooth® |
DISPLAY |
Five-inch LCD, 800 x 480 pixel, 500 NIT |
KEYS/BUTTONS |
Flat membrane panel, tactile feel 18 buttons plus 5 softkeys and power
|
TEMPERATURE RANGE |
Legal: 14°F to 104°F (-10°C to 40°C) Industrial: 14°F to 122°F (-10°C to 50°C) |
DIMENSIONS (W X H X D): |
11.6 x 8.6 x 4.0 in (29.47 x 21.85 x 10.16 cm) With RJ45 option: 11.6 x 8.6 x 4.5 in (29.47 x 21.85 x 11.43 cm) |
WEIGHT |
6.25 lb (3 kg) |
WARRANTY |
Two-year limited warranty |
Approvals |
NTEP CC 19-021, Class III/IIIL, 10,000d Measurement Canada AM-6121, Class III/IIIHD, 10,000d OIML pending EU-NAWI pending cULus CE UKCA |
