Imada GEK030-C3E - Digital Ratchet Torque Wrench, 13.4~265.4 lbf-in
Digital Ratchet Torque Wrenches have a forged steel ratchet head and feature a unique power sensor in the ergonomic handle which accurately detects and analyzes load applied to the grip to enable more precise torque measurement regardless of hand position, unlike other loading point sensitive wrenches. more ...
High accuracy ±1.5% F.S. both CW and CCW directions
The best known, rugged, high quality tools for over 60 years!
Peak, peak with auto zero reset and Real Time modes
Five programmable torque presets ideal for frequent operations.
Pass/Fail mode counts fasteners tightened within programmed High/Low limits, using LED and audible alerts
Selectable units, lbf-in, lbf-ft, kgf-cm, N-m
ISO-6789 Compliant
Calibration certificate traceable to NIST and carrying case included
Rigid Ergonomic Grip with Unique Power Sensor - keeps the load point in the center of your hand. The built-in sensor accurately detects and analyzes load applied to the grip to enable more precise torque measurement regardless of hand position and skill level of the operator.
Large LED Lamp - is easily visible even from the side
Digital Ratchet Torque Wrenches have a forged steel ratchet head and feature a unique power sensor in the ergonomic handle which accurately detects and analyzes load applied to the grip to enable more precise torque measurement regardless of hand position, unlike other loading point sensitive wrenches.
These torque wrenches measure in peak mode, peak with auto zero reset, and real time. Five programmable torque presets stored in memory enable the user to check frequently used values. The presets alert the user with an intermittent signal at 90% and a continuous signal at 100% of the preset torque value using LED?and audible indicators that enable users to tighten to within 10% of a preset torque value. Pass/Fail mode counts the number of fasteners tightened within programmed high and low torque limits. Selectable units of lbf-in, lbf-ft, kgf-m, and N-m. Uses a lithium coin battery, CR2354.
Specifications:
Accuracy - ±1.5% F.S.
Measuring direction - CW and CCW
Measuring unit - Selectable lbf-in, lbf-ft, kgf-m, N-m
