Mark-10 SJR025 Miniature Force Sensors, 0.25 x 0.0001 lb

Mark-10 - Force and Torque Measurement Products
Extremely compact force measurement sensor for tensile and compressive loads in applications with limited space. The Series SJR is available in capacities from 0.25 lb to 100 lb (1 N to 500 N). The sensors feature terrific mechanical overload protection more ...
Scales > Force Gauge > Force Sensor
Mark-10 SJR025 Miniature Force Sensors, 0.25 x 0.0001 lb




Call for more info
Download PDF
Mark-10 SJR025 Miniature Force Sensors, 0.25 x 0.0001 lb
FREE Ground Shipping *


Price: $945.25


In Stock - Ships within 24 hours

View Features

Mark 10
SKU: SJR025

Features

Extremely compact force measurement sensor for tensile and compressive loads in applications with limited space. The Series SJR is available in capacities from 0.25 lb to 100 lb (1 N to 500 N). Every capacity has the same miniature dimensions: 0.85 x 0.30 x 0.75 (21.6 mm x 7.6 mm x 19.1 mm). The sensors feature outstanding mechanical overload protection of up to 1,000% percent of full scale for most applications and threaded holes on two sides for the mounting of attachments or implements.

  • Member of the BGI family of interchangeable sensors
  • Personality module holds all calibration and configuration data
  • Measures tensile and compressive forces
  • Mechanical overload protection of up to 1,000% of full scale for all models, 200% for SJR50 and SJR100 when used in tension only
  • NIST-traceable certificate of calibration included
  • Accuracy: ± 0.2% of full scale ±1 digit + BGI
  • Weight: 0.015 lbs (0.007 kg)
  • dimensions: 0.85 x 0.30 x 0.75 (21.6 mm x 7.6 mm x 19.1 mm
  • Warranty: 3 years
Model Capacity x Resolution
SJR025 0.25 X 0.0001 lb 100 x 0.05 gF 1 x 0.0005 N
SJR05 0.5 x 0.0002 lb 250 x 0.1 gF 2.5 x 0.001 N
SJR2 2 x 0.001 lb 1 x 0.0005 kgF 10 x 0.005 N
SJR5 5 x 0.002 lb 2.5 x 0.001 kgF 25 x 0.01 N
SJR10 10 x 0.005 lb 5 x 0.002 kgF 50 x 0.02 N
SJR20 20 x 0.01 lb 10 x 0.005 kgF 100 x 0.05 N
SJR50 50 x 0.02 lb 25 x 0.01 kgF 250 x 0.1 N
SJR100 100 x 0.05 lb 50 x 0.02 kgF 500 x 0.2 N

Weight: 2.00 lb
