Mark-10 SSM100 Inline Compression and Tension Testing Sensor, 100 x 0.05 lb

Mark-10 - Force and Torque Measurement Products
Force measurement sensor for tensile and compressive loads in a wide variety of applications, available in capacities from 0.25 lb to 100 lb. Thread on two sides can accept a variety of hooks and implements, making this sensor well suited for inline tests more ...
Scales > Force Gauge > Force Sensor
Mark-10 SSM100 Inline Compression and Tension Testing Sensor, 100 x 0.05 lb




Call for more info
Download PDF
Mark-10 SSM100 Inline Compression and Tension Testing Sensor, 100 x 0.05 lb
FREE Ground Shipping *


Price: $617.00


In Stock - Ships within 24 hours

View Features

Mark 10
SKU: SSM100

Features

Force measurement sensor for tensile and compressive loads in a wide variety of applications, available in capacities from 0.25 lb to 100 lb. Thread on two sides can accept a variety of hooks and implements, making this sensor particularly well suited for inline tests.

  • Member of the BGI family of interchangeable sensors
  • Personality module holds all calibration and configuration data
  • Rugged aluminum housing
  • Measures tensile and compressive forces
  • Remote operation
  • Small Size
  • NIST-traceable certificate of calibration included
  • Accuracy: ± 0.15% of full scale ±1 digit + BGI
  • Weight: 0.4 lbs (0.2 kg)
  • Warranty: 3 years
Model Capacity x Resolution Price
SSM025 0.25 X 0.0001 lb, 100 x 0.05 gF, 1 x 0.0005 N $736
SSM05 0.5 x 0.0002 lb, 250 x 0.1 gF, 2.5 x 0.001 N $736
SSM2 2 x 0.001 lb, 1 x 0.0005 kgF, 10 x 0.005 N $617
SSM5 5 x 0.002 lb, 2.5 x 0.001 kgF, 25 x 0.01 N $617
SSM10 10 x 0.005 lb, 5 x 0.002 kgF, 50 x 0.02 N $617
SSM20 20 x 0.01 lb, 10 x 0.005 kgF, 100 x 0.05 N $617
SSM50 50 x 0.02 lb, 25 x 0.01 kgF, 250 x 0.1 N $617
SSM100 100 x 0.05 lb, 50 x 0.02 kgF, 500 x 0.2 N $617
AC1018 Mounting kit, SS/SSM to TS-Series test stands $95

Weight: 2.00 lb

* within the 48 continental US States
