Features
Ohaus Explorer lab scales have multiple weighing modes, auto zero tracking, RS232, GLP, auto tare. Custom LCD with 7 characters, four user-friendly applications and more. Capacity x precision: 100/210 g x 0.0001/0.001 g
The Explorer Pro Series of standard level balances was designed for simplicity and includes the industry’s easiest user interface for easy setup and operation; no training is required. The Explorer Pro offers all the features and durability found in high-end laboratory balances plus the traditional Ohaus quality and support for years of trouble free use!
- Simple 2 key menu operation and navigation
- Ready to weigh without complicated setup
- Innovative man-machine interface and user promps make Explorer Pros advanced applications easy to follow and easy to use
- Three soft keys are application specific allowing direct access to items such as calibration, units, new sample, sample size, new reference weight, reference weight, new target and/or target
- Flexibility to display either simple weighing results or more advanced results including piece count, average piece weight, sample size, tare weight, weight, under and over indicators
- Selectable operating languages including English, Spanish, Italian, French and German
- 7 Built-in application modes plus below balance weighing: animal weighing, parts counting, percent weighing, check weighing, filling and gross/net/tare
- Only Explorer Pros applications and dot matrix display allow for simultaneous viewing of reference information including piece count, percent, under/over/accept and actual weight
- Perform animal weighing procedures in either manual, semi-auto or automatic modes
- Parts counting also includes parts counting check and parts counting fill functions
- Percent weighing with targets defined either as a percent or weight
- Check weighing with primary results displayed either as a weight or a message (under, accept, over)
- Filling application with fill guide displaying the relationship between the total load on the platform and a target
- Gross/net/tare applications displays G/N/T values simultaneously
- Brilliant backlit high resolution dot matrix display
- Enhances viewing in any environment
- Simplifies menu navigation and balance set up
- Display additional results and reference information in each application screen view
- Capacity guide provides a visual aid by displaying the relationship between the total platform load and the full balance capacity
- Fill guide provides a visual aid by displaying the relationship between the total platform load and a user difined target
- Standard RS232 port for easy communication with computer or printer
- GLP compliant with user selectable outputs - complete GLP/GMP capabilities including date, time, balance ID, user name, project name and reference information
- Protective in-use cover and security bracket included
- Standard auxiliary port - flexibility for use in legal applications requiring secondary display
- Standard in-use cover - spill protection at no additional cost
- Below balance weighing with integral weigh-below hook
- Integral security bracket permits locking balance with cable
- Industry leading warranty and support
- NTEP Legal For Trade approved models available
| Model Number: |
EP64 |
EP114 |
EP214 |
EP214D |
| Capacity (*draft shield included) |
*62 g |
*110 g |
*210 g |
*100/210 g |
| Readability (g) |
0.0001 |
0.0001 |
0.0001 |
0.0001/0.001 |
| Weighing Modes |
g, mg, oz, oz t, ct, dwt, taels (3), mommes, gn, ti, N, custom unit |
| Repeatability (std dev) |
0.1 mg |
0.1 / 0.5 mg |
| Linearity |
± 0.2 mg |
± 0.2/0.5 mg |
| Power requirements |
110-120 V ac, 220-240 V ac, 50/60 Hz |
| Display |
0.6" (1.5 cm) |
| Platform size |
3.5" (9 cm) diameter |
| Dimensions (W x H x D) |
9" x 15.3" x 14" (22.8 x 38.7 x 35.5 cm) |
Weight:
30.00 lb
|
2 Year Manufacture Warranty
|
