Sartorius Cubis II Percision Balances 0.01 g	Authorized Dealer
The Cubis® was developed for users, who expect the best possible performance from a lab balance across the board but only want to invest in what is necessary. For this reason, Sartorius has gone far beyond simply further developing what already exists. The new Cubis® represents a groundbreaking new concept.
Sartorius Scales >> Analytical Laboratory Balances

MCA

Sartorius MCA6202S0-S00 Cubis-II Precision Balance - Toploading 8.11 x 8.11 inch pan and QP99 Package 6200 x 0.01 g

Draft Shield 0

MCE

Sartorius MCE6202S0-S00 Cubis-II Precision Balance - Preconfigured Toploading 8.11 x 8.11 inch pan 6200 x 0.01 g

The New Generation of Modular Premium Laboratory Balances

For scientists in R&D and analytical laboratories needing the most reliable lab weighing results, the Cubis® II from Sartorius is a completely configurable, high performance portfolio of balance hardware and software that will align with your unique demands and compliance requirements to maximize operational efficiency and experimental outcomes.

All modules of the Cubis® II balance were designed for an intuitive operation, further aided by intelligent diagnostic systems. These design elements guarantee a higher degree of repeatability for different workflows while lowering the probability of human error during measurement.

Trusted Results The Cubis® II balance offers several advantages over other lab balances:

Leading Performance: the Cubis® II balance offers best-in-class performance, including high-capacity and high readability, regardless of sample type
Error-free Operations: Ensure a high level of trust and transparency by using Cubis® II’s functionality to assess relevant factors during data acquisition.
Full End-to-End Data Integrity: Ensure your data is reliable and cannot be manipulated with Cubis® II’s user management function and LIMS connectivity.
Reliable Support: Our lab weighing team provides expert support to help ensure your success, even when making very specific and/or unique requests.

Sartorius Cubis II Analytical Balances 0.01 g

FREE UPS Ground Shipping
(within the 48 continental US States)

Specifications Chart
1200 x 0.01 g
2200 x 0.01 g
4200 x 0.01 g

Specifications Chart
5200 x 0.01 g

Specifications Chart
6200 x 0.01 g
8200 x 0.01 g

Specifications Chart
1500 x 0.01g
3000 x 0.02g
6200 x 0.05g

Specifications Chart
10200 x 0.01 g
14200 x 0.01 g

Specifications Chart
3500 x 0.01g
7000 x 0.02g
14200 x 0.05g

The modular weighing system Cubis® II can be individually configured from different components. The combinability of the display unit, weighing module, draft shield, software packages for various applications and functions and a comprehensive range of accessories allows the individual adaptation of the Cubis® II balance to all weighing tasks. The Cubis® II range of premium laboratory balances with a maximum load between 2.1 g and 70 kg and a readability between 0.1 ìg to 1 g provide the ideal model for every application.

Cubis® II Display and Control Units

Advances User Interface MCA

Large 7“ color touch display including touch, scroll, swipe functionality with factory installed essential weighing applications and diverse QApp Packages for optional software extension. Features:

High-performance touch screen with high resolution and brilliant colors
Modern user guidance with outstanding ease of use, even in complex lab situations

Essential User Interface MCE

Large, high-contrast touch display with factory-installed essential weighing applications for easy operation of highest weighing performance. Features:

For users who do not have complex applications but need to weigh with the highest level of accuracy
High-contrast touch display with clearly structured functionality
Easy-to-use essential weighing applications included

Sartorius Cubis II Percision Balances 0.01 g Specs:

Model	MCA5202S-2S00-A	MCE5202S-2S00-A	MCA5202S-2S00-E	MCE5202S-2S00-E	MCA5202S-2S00-I	MCE5202S-2S00-I	MCA5202S-2S00-R	MCE5202S-2S00-R	MCA5202S-2S00-U	MCE5202S-2S00-U
Price	$10,072.50	$9,265.00	$7,060.10	$6,252.60	$11,313.50	$10,506.00	$7,060.10	$6,252.60	$7,556.50	$6,749.00
Capacity x Readability	5200 g x 0.01 g	5200 g x 0.01 g	5200 g x 0.01 g	5200 g x 0.01 g	5200 g x 0.01 g	5200 g x 0.01 g	5200 g x 0.01 g	5200 g x 0.01 g	5200 g x 0.01 g	5200 g x 0.01 g
Draft Shield Type	Draft Shield A Automatic analytical balance draft shield with learning function for all models with 0.01 mg, 0.1 mg or 1 mg		Draft Shield E Manual draft shield for all models with 1 mg readability		Draft Shield I Automatic draft shield with integrated ionizer and with learning capability for semi-micro and analytical balances		Draft Shield R Removable, flat draft shield frame made of stainless steel for all models with 1 mg readability.		Draft Shield U Manual analytical balance draft shield for all models with 0.01 mg, 0.1 mg or 1 mg
QApp Packages	MCA Included in every Cubis® balance: Mixing, Statistics, Totalization, Solids density, Percentage weighing, Multiplication, Averaging, Checkweighing, Highest peak value, Counting MCE Factory installed basic set of essential weighing applications
Display	MCA Advanced User Interface	MCE Essential User Interface	MCA Advanced User Interface	MCE Essential User Interface	MCA Advanced User Interface	MCE Essential User Interface	MCA Advanced User Interface	MCE Essential User Interface	MCA Advanced User Interface	MCE Essential User Interface
Repeatability at 5 % load Standard deviation of the load values, tolerance	1 mg
Repeatability at 5 % load Standard deviation of the load values, typical value	0.6 mg
Repeatability near Max Standard deviation of the load values, tolerance	1 mg
Repeatability near Max Standard deviation of the load values, typical value	0.6 mg
Linearity Deviation	Tolerance 5 mg Typical value 2 mg
Interfaces	USB A, B, C, RS232, and Ethernet
	Deviation at eccentric loading, positions according to OIML R76
Test weight	2000 g
Tolerance	2 mg
Typical value	1 mg
Sensitivity drift between +10 ^oC and +30 ^oC	1 ppm/K
	Tare maximum capacity: Less than 100 % of maximum capacity
Accuracy class according to Directive 2014/31/EU	I
Verification scale interval (e) according to Directive 2014/31/EU	10 mg
Minimum load (Min) according to Directive 2014/31/EU	100 mg
	Minimum weight according to USP (United States Pharmacopeia), Chap. 41
Optimum minimum weight	820 mg
Typical minimum weight	1200 mg
Typical stabilization time	1 s
Typical measurement time	2 s
Recommended calibration weight	5000 g E2
Recommended calibration weight	5000 g E2	5000 g E2	5000 g E2	5000 g E2	5000 g E2	5000 g E2	5000 g E2	5000 g E2	5000 g E2	5000 g E2
	Dimensions
MCE/MCA Weighing module (L x W x H)*	Draft-Sld A, I, U 425 x 240 x 373 mm Draft-Sld E 425 x 240 x 284 mm Draft-Sld R 425 x 240x 122 mm
Electronics module (L x W x H)	MCA 355 x 260 x 61 mm MCE 315 x 240 x 61 mm
Weighing pan size	140 x 140 mm
Weight, approx.*	5.9/7.5/9.4/10.2 kg*

* depending upon weighing pan size, filter weighing pan and draft shield
Country of origin Germany

Model	MCA1202S-2S00-0	MCE1202S-2S00-0	MCA2202S-2S00-0	MCA2202S0-S00	MCE2202S-2S00-0	MCA4202S-2S00-0	MCA4202S0-S00	MCE4202S-2S00-0
Price	$4,870.50	$4,063.00	$5,312.50	$7,616.00	$4,505.00	$5,754.50	$8,058.00	$4,947.00
Preconfigured Model	-	-	-	-	MCE2202S0-S00	-	-	-
Preconfigured Price	-	-	-	-	$4,505.00	-	-	-
Capacity x Readability	1200 x 0.01 g	1200 x 0.01 g	2200 x 0.01 g	2200 x 0.01 g	2200 x 0.01 g	4200 x 0.01 g	4200 x 0.01 g	4200 x 0.01 g
Draft Shield Type	Draft Shield 0 Flat Stainless Steel Pan
Software	MCA Included in every Cubis® balance: Mixing, Statistics, Totalization, Solids density, Percentage weighing, Multiplication, Averaging, Checkweighing, Highest peak value, Counting MCE Factory installed basic set of essential weighing applications
Added Software	-	-	-	QP99	-	-	QP99	-
Display	MCA Advanced User Interface	MCE Essential User Interface	MCA Advanced User Interface	MCA Advanced User Interface	MCE Essential User Interface	MCA Advanced User Interface	MCA Advanced User Interface	MCE Essential User Interface
Repeatability at 5 % load Standard deviation of the load values, tolerance	7 mg
Repeatability at 5 % load Standard deviation of the load values, typical value	4 mg
Repeatability near Max Standard deviation of the load values, tolerance	7 mg
Repeatability near Max Standard deviation of the load values, typical value	4 mg
Linearity Deviation	Tolerance 20 mg Typical value 6 mg
Interfaces	USB A, B, C, RS232, and Ethernet
	Deviation at eccentric loading, positions according to OIML R76
Test weight	500 g			1000 g			2000 g
Tolerance	20 mg						30 mg
Typical value	10 mg
Sensitivity drift between +10 ^oC and +30 ^oC	2 ppm/K
	Tare maximum capacity: Less than 100 % of maximum capacity
Accuracy class according to Directive 2014/31/EU	II
Verification scale interval (e) according to Directive 2014/31/EU	100 mg
Minimum load (Min) according to Directive 2014/31/EU	500 mg
	Minimum weight according to USP (United States Pharmacopeia), Chap. 41
Optimum minimum weight	8200 mg
Typical minimum weight	8200 mg
Typical stabilization time	0.8 s
Typical measurement time	1 s						1.5 s
Recommended calibration weight	700 g E2			1500 g E2			3000 g E2
Recommended calibration weight	700 g E2	700 g E2	1500 g E2	1500 g E2	1500 g E2	3000 g E2	3000 g E2	3000 g E2
	Dimensions
MCE/MCA Weighing module (L x W x H)*	425 x 240 x 95
Electronics module (L x W x H)	MCA 355 x 260 x 61 mm MCE 315 x 240 x 61 mm
Weighing pan size	206 x 206 mm
Weight, approx.*	5.4 kg*

* depending upon weighing pan size, filter weighing pan and draft shield
Country of origin Germany

Model	MCA6202S0-S00	MCA6202S-2S00-0	MCE6202S-2S00-0	MCA6202P-2S00-0	MCE6202P-2S00-0	MCA8202S-2S00-0	MCE8202S-2S00-0
Price	$8,806.00	$6,502.50	$5,695.00	$5,916.00	$5,108.50	$7,250.50	$6,443.00
Preconfigured Model	-	-	MCE6202S0-S00	-	-	-	-
Preconfigured Price	-	-	$5,695.00	-	-	-
Capacity x Readability	6200 x 0.01 g	6200 x 0.01 g	6200 x 0.01 g	1500 x 0.01 g 3000 x 0.02 g 6200 x 0.05 g	1500 x 0.01 g 3000 x 0.02 g 6200 x 0.05 g	8200 x 0.01 g	8200 x 0.01 g
Draft Shield Type	Draft Shield 0 Flat Stainless Steel Pan
Software	All Inclusive Package QP99 - The software application package All inclusive includes 4 different sub-packages for compliance (Pharma (QP1)), complex weighing applications (Advanced (QP2)), weighing applications and helpful tools (Utilities (QP3)) and connectors for data exchange (Connectivity (QP4)).	MCA Included in every Cubis® balance: Mixing, Statistics, Totalization, Solids density, Percentage weighing, Multiplication, Averaging, Checkweighing, Highest peak value, Counting MCE Factory installed basic set of essential weighing applications
Display	MCA Advanced User Interface		MCE Essential User Interface	MCA Advanced User Interface	MCE Essential User Interface	MCA Advanced User Interface	MCE Essential User Interface
Repeatability at 5 % load Standard deviation of the load values, tolerance	7 mg
Repeatability at 5 % load Standard deviation of the load values, typical value	4 mg
Repeatability near Max Standard deviation of the load values, tolerance	7 mg			40 mg		7 mg
Repeatability near Max Standard deviation of the load values, typical value	4 mg			15 mg		4 mg
Linearity Deviation	Tolerance 20 mg Typical value 6 mg			Tolerance 50 mg Typical value 20 mg		Tolerance 20 mg Typical value 6 mg
Interfaces	USB A, B, C, RS232, and Ethernet
	Deviation at eccentric loading, positions according to OIML R76
Test weight	2000 g					5000 g
Tolerance	20 mg			50 mg		20 mg
Typical value	10 mg			30 mg		10 mg
Sensitivity drift between +10 ^oC and +30 ^oC	2 ppm/K
	Tare maximum capacity: Less than 100 % of maximum capacity
Accuracy class according to Directive 2014/31/EU	II
Verification scale interval (e) according to Directive 2014/31/EU	100 mg
Minimum load (Min) according to Directive 2014/31/EU	500 mg
	Minimum weight according to USP (United States Pharmacopeia), Chap. 41
Optimum minimum weight	8200 mg
Typical minimum weight	8200 mg
Typical stabilization time	0.8 s
Typical measurement time	1.5 s
Recommended calibration weight	5000 g E2			5000 g E2		7000 g E2
Recommended calibration weight	5000 g E2	5000 g E2	5000 g E2	5000 g E2	5000 g E2	7000 g E2	7000 g E2
	Dimensions
MCE/MCA Weighing module (L x W x H)*	425 x 240 x 95
Electronics module (L x W x H)	MCA 355 x 260 x 61 mm MCE 315 x 240 x 61 mm
Weighing pan size	206 x 206 mm
Weight, approx.*	5.4 kg*

* depending upon weighing pan size, filter weighing pan and draft shield
Country of origin Germany

Model	MCA10202S-2S00-0	MCE10202S-2S00-0	MCA14202S-2S00-0	MCE14202S-2S00-0	MCA14202P-2S00-0	MCE14202P-2S00-0
Price	$8,262.00	$7,454.50	$9,953.50	$9,146.00	$8,704.00	$7,896.50
Capacity x Readability	10200 x 0.01 g	10200 x 0.01 g	14200 x 0.01 g	14200 x 0.01 g	3500 x 0.01 g 7000 x 0.02 g 14200 x 0.05 g	3500 x 0.01 g 7000 x 0.02 g 14200 x 0.05 g
Draft Shield Type	Draft Shield 0 Flat Stainless Steel Pan
Software	MCA Included in every Cubis® balance: Mixing, Statistics, Totalization, Solids density, Percentage weighing, Multiplication, Averaging, Checkweighing, Highest peak value, Counting MCE Factory installed basic set of essential weighing applications
Display	MCA Advanced User Interface	MCE Essential User Interface	MCA Advanced User Interface	MCE Essential User Interface	MCA Advanced User Interface	MCE Essential User Interface
Repeatability at 5 % load Standard deviation of the load values, tolerance	7 mg		10 mg
Repeatability at 5 % load Standard deviation of the load values, typical value	5 mg
Repeatability near Max Standard deviation of the load values, tolerance	7 mg		10 mg		10 mg
Repeatability near Max Standard deviation of the load values, typical value	5 mg		5 mg		5 mg
Linearity Deviation	Tolerance 20 mg Typical value 6 mg		Tolerance 30 mg Typical value 10 mg		Tolerance 50 mg Typical value 20 mg
Interfaces	USB A, B, C, RS232, and Ethernet
	Deviation at eccentric loading, positions according to OIML R76
Test weight	5000 g
Tolerance	20 mg		20 mg		40 mg
Typical value	10 mg		10 mg		10 mg
Sensitivity drift between +10 ^oC and +30 ^oC	1.5 ppm/K
	Tare maximum capacity: Less than 100 % of maximum capacity
Accuracy class according to Directive 2014/31/EU	II
Verification scale interval (e) according to Directive 2014/31/EU	100 mg
Minimum load (Min) according to Directive 2014/31/EU	1000 mg
	Minimum weight according to USP (United States Pharmacopeia), Chap. 41
Optimum minimum weight	8200 mg
Typical minimum weight	8200 mg
Typical stabilization time	0.8 s
Typical measurement time	1.5 s
Recommended calibration weight	10000 g E2		14000 g E2		14000 g E2
	Dimensions
MCE/MCA Weighing module (L x W x H)*	425 x 240 x 95
Electronics module (L x W x H)	MCA 355 x 260 x 61 mm MCE 315 x 240 x 61 mm
Weighing pan size	206 x 206 mm
Weight, approx.*	5.4 kg*
