Minebea-Intec Combics 2 IS Series Platform Scales SHIMPO Equipment
Authorized Dealer
The weighing platform is a component of a modular scale, consisting of the weighing platform and an indicator (which is comprised of an analog/digital converter and a display and operator terminal), such as a Combics CAIXS2 indicator
Minebea-Intec Combics 2 IS Series Platform Scales Call Sales 800-832-0055

Specifications Chart

Accessories

Combics provides support in all areas of your process chain, from manual formulations up to PC controlled production checks. The modular system allows tailor-made configuration of the individual components for each area. We also produce individual complete solutions according to your specific applications.

Standard Features
  • Display LCD, backlit with 20mm weight value
  • Standard data interface RS232 via D-SUB 25-pin connector
  • One scale connection in total (analog or digital)
  • Material: stainless steel, ingress protection: IP69k

Minebea-Intec Combics 2 IS Series Platform Scales

FREE UPS Ground Shipping
(within the 48 continental US States)

Must be ordered with Scale
Minebea Internal Calibration for Series Platforms - must be ordered with the unit - Standard on EDE and IGG
Minebea Internal Calibration for Series Platforms - must be ordered with the unit - Standard on EDE and IGG, add $300.00
Minebea Below Scale Weighing IS Series Platforms - must be ordered with the Unit
Minebea Below Scale Weighing IS Series Platforms - must be ordered with the Unit, add $220.00




The robust, high resolution weighing platforms of the Industry Supreme series offer reliable overload protection and are based on monolithic weighing technology with up to 640,000 divisions. Its high resolution guarantees precise measurement results and thus less product loss. An integrated calibration weight adjustment ensures consistent precision

  • The standard RS-485 interface is X-bus compatible. An RS-232C interface is optionally available. Power requirements range from 10.6 VDC to 30 VDC.
  • At the touch of the unique ISO TEST key, the IS platform calibrates and adjusts itself automatically using a built-in calibration weight
  • High internal resolution guarantees reliable weight readouts
  • Weighing results: up to 50 times/second
  • All scales come standard with stainless steel load plate (wrap-around design optional). High IP rating for ideal protection.

Combics Indicator CAISL (IP44)

  • Display LCD, backlit with 20mm weight value
  • Integrated LED's for checkweighing (red-green-yellow)
  • Standard data interface RS232 via D-SUB 25-pin connector, PS/2 connector
  • Two scale connections in total (analog or digital)
  • Basic applications: weighing, counting, animal weighing, checkweighing, sorting, totalizing, net-total, averaging, percent weighing
  • Material: stainless steel, ingress protection: IP44
  • Clock option Standard for date and time

Combics Indicator CAIS (IP69K)

  • Display LCD, backlit with 20mm weight value
  • Integrated LED's for checkweighing (red-green-yellow)
  • Standard data interface RS232 via cable gland
  • Two scale connections in total (analog or digital)
  • Basic applications: weighing, counting, animal weighing, checkweighing, sorting, totalizing, net-total, averaging, percent weighing
  • Material: stainless steel, ingress protection: IP69k
  • Clock option standard for date and time
Model ISBBP-06-H-CAISL2-IP44 ISBBP-3-H-CAISL2-IP44 ISBBP-6-H-CAISL2-IP44 ISBBS-3-H-CAIS2-IP69k ISBBS-6-H-CAIS2-IP69k ISDCP-6-S-CAISL2-IP44 ISDCS-16-H-CAISL2-IP44 ISDCS-35-H-CAISL2-IP44
Minebea ISBBP-06-H-CAISL2-IP44 Combics 2 IS Scale 4.5 in diameter Painted Steel - 0.62 kg x 0.001 g
$4,491.00
buy now
Minebea ISBBP-3-H-CAISL2-IP44 Combics 2 IS Scale 7.1 x 7.1 in Painted Steel - 3.1 kg x 0.01 g
$4,124.70
buy now
Minebea ISBBP-6-H-CAISL2-IP44 Combics 2 IS Scale 7.1 x 7.1 in Painted Steel - 6.1 kg x 0.01 g
$4,811.40
buy now
Minebea ISBBS-3-H-CAIS2-IP69k Combics 2 IS Scale 7.1 x 7.1 in Stainless Steel - 3.1 kg x 0.01 g
$6,167.70
buy now
Minebea ISBBS-6-H-CAIS2-IP69k Combics 2 IS Scale 7.1 x 7.1 in Stainless Steel - 6.1 kg x 0.01 g
$6,494.40
buy now
Minebea ISDCP-6-S-CAISL2-IP44 Combics 2 IS Scale 13.7 x 9.5 in Painted Steel - 6.2 kg x 0.1 g
$4,166.10
buy now
Minebea ISDCS-16-H-CAISL2-IP44 Combics 2 IS Scale 15.8 x 11.8 in Stainless Steel - 16 kg x 0.1 g
$5,631.30
buy now
Minebea ISDCS-35-H-CAISL2-IP44 Combics 2 IS Scale 15.8 x 11.8 in Stainless Steel - 34 kg x 0.1 g
$6,546.60
buy now
Indicator IP Rating IP44 IP44 IP44 IP69k IP69k IP44 IP44 IP44
Model Base Only ISBBP-06-H ISBBP-3-H ISBBP-6-H ISBBS-3-H ISBBS-6-H ISDCP-6-S ISDCS-16-H ISDCS-35-H
Minebea ISBBP-06-H IS Platform  4.5 in diameter Painted Steel  (Base Only )- 0.62 kg x 0.001 g
$2,884.50
buy now
Minebea ISBBP-3-H IS Platform 7.1 x 7.1 inch Painted Steel   (Base Only) -3.1 kg  x 0.01 g
$2,518.20
buy now
Minebea ISBBP-6-H IS Platform 7.1 x 7.1 inch Painted Steel  (Base Only) -6.2 kg  x 0.01 g
$3,204.90
buy now
Minebea ISBBS-3-H IS Platform 7.1 x 7.1 inch Stainless Steel (Base Only) -3.1 kg  x 0.01 g
$4,303.80
buy now
Minebea ISBBS-6-H Platform 7.1 x 7.1 inch Stainless Steel (Base Only) - 6.2 kg x 0.01 g
$4,630.50
buy now
Minebea ISDCP-6-S IS Platform 13.7 x 9.5 inch Painted Steel  (Base Only) -6.2 kg  x 0.1 g
$2,559.60
buy now
Minebea ISDCS-16-H IS Platform 15.8 x 11.8 inch Stainless Steel (Base Only) -16  kg  x 0.1 g
$4,024.80
buy now
Minebea IISDCS-35-H IS Platform 15.8 x 11.8 inch Stainless Steel (Base Only) -34  kg  x 0.1 g
$4,940.10
buy now
Capacity x Readability 0.62 kg x 0.001 g 3.1 kg x 0.01 g 6.2 kg x 0.01 g 3.1 kg x 0.01 g 6.2 kg x 0.01 g 6.2 kg x 0.1 g 16 kg x 0.1 g 34 kg x 0.1 g
Pan Size Ø 4.5 in 7.1 x 7.1 in 7.1 x 7.1 in 7.1 x 7.1 in 7.1 x 7.1 in 13.7 x 9.5 in 15.8 x 11.8 in 15.8 x 11.8 in
Ship Wgt 18 lb 19 lb 19 lb 19 lb 19 lb 19 lb 41 lb 41 lb
IP Rating IP43 IP54 IP54 IP65 IP65 IP54 IP43 IP43
Material Painted Steel Painted Steel Painted Steel Stainless Steel Stainless Steel Painted Steel Stainless Steel Stainless Steel
Humidity 85% relative (non-condensing) to 31°C; 50% relative to 40°C
Altitudes Use at altitudes above sea level Up to 2000 m, in interior spaces
Calibration EXternal Calibration Weight
Data interface RS-485
Cable Length 6 ft 9 ft
Calibration weight 500 g E2 2000 g E2 5000 g E2 2000 g E2 5000 g E2 5000 g E2 10000 g F1 10000 g F1
Dimensions 266 x 236 x 146 mm 266 x 236 x 117 mm 280 x 250 x 123 mm 266 x 236 x 117 mm 280 x 250 x 123 mm 350 x 240 x 134 mm 400 x 300 x 120 mm 400 x 300 x 120 mm





Model ISEDE-16-HV1-CAIS2-IP69k ISEDE-34-HV1-CAIS2-IP69k ISEDE-64-SV1-CAIS2-IP69k ISEDE-64-HV1-CAIS2-IP69k ISIGG-150-HV1-CAIS2-IP69k ISIGG-300-HV1-CAIS2-IP69k ISEDE-16-DS1-CAIS2-IP69k ISIGG-150-DS1-CAIS2-IP69k ISIGG-300-DS1-CAIS2-IP69k
Minebea ISEDE-16-HV1-CAIS2-IP69k Combics 2 IS Scale 15.8 x 11.8 in Painted Steel - 16 kg x 0.1 g
$5,796.90
buy now
Minebea ISEDE-34-HV1-CAIS2-IP69k Combics 2 IS Scale 15.8 x 11.8 in Painted Steel - 34 kg x 0.1 g
$6,255.00
buy now
Minebea ISEDE-64-SV1-CAIS2-IP69k Combics 2 IS Scale 15.8 x 11.8 in Painted Steel - 64 kg x 1 g
$6,667.20
buy now
Minebea ISEDE-64-HV1-CAIS2-IP69k Combics 2 IS Scale 15.8 x 11.8 in Painted Steel - 64 kg x 0.1 g
$8,452.80
buy now
Minebea ISIGG-150-HV1-CAIS2-IP69k Combics 2 IS Scale 32 x 24 in Painted Steel - 150 kg x 1 g
$8,718.30
buy now
Minebea ISIGG-300-HV1-CAIS2-IP69k Combics 2 IS Scale 32 x 24 in Painted Steel - 300 kg x 2 g
$8,718.30
buy now
Minebea ISEDE-16-DS1-CAIS2-IP69k Combics 2 IS Scale 15.8 x 11.8 in Painted Steel - 16 kg x 0.01 g
$6,692.40
buy now
Minebea ISIGG-150-DS1-CAIS2-IP69k Combics 2 IS Scale 32 x 24 in Painted Steel - 150 kg x 0.1 g
$9,219.60
buy now
Minebea ISIGG-300-DS1-CAIS2-IP69k Combics 2 IS Scale 32 x 24 in Painted Steel - 300 kg x 0.2 g
$9,613.80
buy now
Indicator IP Rating IP69k IP69k IP69k IP69k IP69k IP69k IP69k IP69k IP69k
Model Base Only ISEDE-16-HV1 ISEDE-34-HV1 ISEDE-64-SV1 ISEDE-64-HV1 ISIGG-150-HV1 ISIGG-300-HV1 ISEDE-16-DS1 ISIGG-150-DS1 ISIGG-300-DS1
Minebea ISEDE-16-HV1 IS Platform 15.8 x 11.8 inch Painted Steel (Base Only) -16  kg  x 0.1 g
$3,933.00
buy now
Minebea ISEDE-34-HV1 IS Platform 15.8 x 11.8 inch Painted Steel (Base Only) -34 kg  x 0.1 g
$4,391.10
buy now
Minebea ISEDE-64-SV1 IS Platform 15.8 x 11.8 inch Painted Steel (Base Only) -64 kg  x 1 g
$4,803.30
buy now
Minebea ISEDE-64-HV1 IS Platform 15.8 x 11.8 inch Painted Steel (Base Only) -64 kg  x 0.1 g
$6,588.90
buy now
Minebea ISIGG-150-HV1 IS Platform 32 x 24 inch Painted Steel (Base Only) -150 kg  x 1 g
$6,854.40
buy now
Minebea ISIGG-300-HV1 IS Platform 32 x 24 inch Painted Steel (Base Only) -300  kg  x 2 g
$6,854.40
buy now
Minebea ISEDE-16-DS1 IS Platform 15.8 x 11.8 inch Painted Steel (Base Only) -16  kg  x 0.01 g
$4,828.50
buy now
Minebea ISIGG-150-DS1 IS Platform 32 x 24 inch Painted Steel (Base Only) -150 kg  x 0.1 g
$7,355.70
buy now
Minebea ISIGG-300-DS1 IS Platform 32 x 24 inch Painted Steel (Base Only) -300 kg  x 0.2 g
$7,749.90
buy now
Capacity x Readability 16 kg x 0.1 g 34 kg x 0.1 g 64 kg x 1 g 64 kg x 0.1 g 150 kg x 1 g 300 kg x 2 g 16 kg x 0.01 g 150 kg x 0.1 g 300 kg x 0.2 g
Pan Size 15.8 x 11.8 in 15.8 x 11.8 in 15.8 x 11.8 in 15.8 x 11.8 in 32 x 24 in 32 x 24 in 15.8 x 11.8 in 32 x 24 in 32 x 24 in
Ship Wgt 41 lb 41 lb 41 lb 41 lb 184 lb 184 lb 41 lb 184 lb 184 lb
IP Rating IP65 IP65 IP65 IP65 IP67 IP67 IP65 IP67 IP67
Material Painted Steel Painted Steel Painted Steel Painted Steel Painted Steel Painted Steel Painted Steel Painted Steel Painted Steel
Humidity 85% relative (non-condensing) to 31°C; 50% relative to 40°C
Altitudes Use at altitudes above sea level Up to 2000 m, in interior spaces
Calibration Internal Calibration Weight
Data interface RS-485
Cable Length 9 ft
Calibration weight 10000 g F1 10000 g F1 10000 g F2 10000 g F1 50000 g F2 100000 g F2 10000 g F1 50000 g F2 100000 g F2
Dimensions 400 x 300 x 120 mm 400 x 300 x 120 mm 400 x 300 x 120 mm 400 x 300 x 120 mm 800 x 600 x 117 mm 800 x 600 x 117 mm 400 x 300 x 120 mm 800 x 600 x 117 mm 800 x 600 x 117 mm




Accessories

Model Description Image Price
Interfaces
YDO59IS Data interface with 3-m cable (IP67/ RS-485) and round connector; electrically isolated Sartorius YDO59IS IP67 / RS485 Round Connector
$697.50
buy now
YDO52IS Data interface with 3-m cable (IP67/ RS232/RS423) and round connector; for -FEG or -IGG models Sartorius YDO52IS IP67/RS232/RS485 Round Connector
$697.50
buy now
YDO58IS Data interface with 3-m cable (IP67/ RS-232) and round connector Sartorius YDO58IS IP67 / RS232
$697.50
buy now
YDO56IS Data output port, RS-232 D-Sub 9-pin female, (PC connection), length: 6 m Sartorius YDO56IS RS232 D-Sub 9 Pin Female
$697.50
buy now
YDO57IS Data output port, RS-232 D-Sub 25-pin female connector (PC connection) length: 6 m Sartorius YDO57IS RS232 D-Sub 25 Pin Female Connector (PC Connection) Length: 6m
$697.50
buy now
YDO54IS Data interface (IP65/ RS232) round connector for IS06BBE, IS2CCE, IS6CCE, IS12CCE Sartorius YDO54IS IP65 / RS232 Round Connector
$697.50
buy now
Cables
YCC01-01ISM6 Extension cable, 12-pin round male connector / 12-pin round female connector, 6 m Sartorius YCC01-01ISM6 Extension Cable
$261.00
buy now
YCC01-0017D2 Connecting cable, from round connector to PC, 25-pin D- Sub, (YDO52IS/YDO54IS/YDO58IS required), 0.2 m Sartorius YCC01-0017D2 Connecting Cable
$238.50
buy now
69QC0010 Round male connector for customizing own cables (quick disconnect with 69QC0011) 12-pin Sartorius 69QC0010 Round Male Connector
$148.50
buy now
69QC0011 Round female connector for customizing own cables (quick disconnect with 69QC0010) 12-pin Sartorius 69QC0011 Connector
$75.00
buy now
Software
YAD01IS Configuration software (PC) for backing up and restoring of settings Sartorius YAD01IS Configuration Software
$571.50
buy now
Mechanical accessories
YEG04IP Pit frame, painted, for IGG platform Sartorius YEG04IP Pit Frame
$1,138.50
buy now
YEG01IP Pit frame, stainless steel, for IGG platform Sartorius YEG01IP Pit Frame Stainless Steel
$3,721.50
buy now
Indicators for direct connection with IS platforms
CAISL1-UV1 Combics 1 (IP44) pre-wired for direct connection to IS platform Minebea CAISL1-UV1 (IP44) Pre-wired For Direct Connection To IS Platform
$1,381.50
buy now
CAISL2-UV1 Combics 2 (IP44) pre-wired for direct connection to IS platform Minebea CAISL2-UV1 (IP44) Pre-wired For Direct Connection To IS Platform
$1,606.50
buy now
CAISL3-UV1 Combics 3 (IP44) pre-wired for direct connection to IS platform Minebea CAISL3-UV1 (IP44) Pre-wired For Direct Connection To IS Platform
$1,876.50
buy now
CAIS2-UV1 Combics 2 (IP69k) pre-wired for direct connection to IS platform Minebea CAIS2-UV1 (IP69k) Pre-wired For Direct Connection To IS Platform
$1,863.90
buy now
CAIS3-UV1 Combics 3 (IP69k) pre-wired for direct connection to IS platform Minebea CAIS3-UV1 (IP44) Pre-wired For Direct Connection To IS Platform
$2,164.50
buy now
