With LCD Display |
With LED Display |
Intercomp offers the industry’s most extensive line of crane scales, and can provide your company with a cost-effective solution to virtually every overhead industrial weighing application - ranging from 25 to 600,000 lbs/ 12.5 to 300,000 kg.
Our advanced design, value-packed with the industry’s most desired features, makes Intercomp the first choice over other electronic units. Ultra high-resolution, A/D conversion delivers unsurpassed accuracy, and digital keypad setup and calibration enhance the ease of operation.
 |
| Legal For Trade |
All crane unit electronics are shock-mounted in a weatherproof case and provide maximum protection against moisture, dust and rough usage. Features include a high-visibility digital readout for easy reading of weights and large pushbutton switches for simple, trouble-free operation.
Low-cost, high performance digital crane scale for medium capacity industrial applications. The unique design flexibility lets you choose the model and weighing capacity you need - NTEP certified from 300 to 20,000 lb/150 to 10,000 kg. The unit utilizes a high-visibility 0.8 inch/20 mm LED digital readout and the efficient micro-controller delivers up to 100 hours of operation on eight (8) D-cell batteries. Crosby eye hook and bottom swivel hook.
With large, easy-to-read LCD or LED displays, CS1500™ high performance crane scales are available in a range of capacities from 500lb (250kg) to 20,000lb (10,000kg), are NTEP certified, and boast best-in-class battery life. Both models come standard with RFX™ Wireless Weighing Technology enabling cable-free control and monitoring of scales. They also feature an optional USB/RS232 output, multi-scale communication, and a multitude of remote display options
|
|
Intercomp 100015 RFX™ Wireless S400™ Indoor Numeric Remote Display
Price: $1,790.00
Out of Stock
 |
|
Intercomp Part 340105-RFX Wireless Thermal Printer with RFX™ Communication Module
Price: $715.50
In Stock
|
Intercomp 101221-RFX PT20 CPU RFX Indicator with Built-in-Printer
Price: $2,695.50
In Stock
|
Intercomp 101225-RFX Handheld Weighing RFX Indicator
Price: $895.50
In Stock
|
Intercomp 140759 IntercompWeigh™ Software
Price: $895.50
In Stock
|
| CS1500 Crane Scales |
| Model |
184500-RFX |
184501-RFX |
184502-RFX |
184503-RFX |
184504-RFX |
184514-RFX |
184515-RFX |
184516-RFX |
184517-RFX |
184518-RFX |
| Price |
$1,885.50
|
$1,885.50
|
$1,885.50
|
$2,425.50
|
$2,425.50
|
$1,885.50
|
$1,885.50
|
$1,885.50
|
$2,425.50
|
$2,425.50
|
Capacity
Graduation |
500 x 0.2 lb
250 x 0.1 kg |
1000 x 0.5 lb
500 x 0.2 kg |
2000 x 1.0 lb
1000 x 0.5 kg |
5000 x 2.0 lb
2500 x 1.0 kg |
10,000 x 5.0 lb
5000 x 2 kg |
500 x 0.2 lb
250 x 0.1 kg |
1000 x 0.5 lb
500 x 0.2 kg |
2000 x 1.0 lb
1000 x 0.5 kg |
5000 x 2.0 lb
2500 x 1.0 kg |
10,000 x 5.0 lb
5000 x 2 kg |
| Legal For Trade |
NTEP #97-135A4 |
| Protection |
IP65 |
| Weight |
29 lb/13 kg |
50 lb/23 kg |
21 lb/10 kg |
25 lb/12 kg |
46 lb/20 kg |
| General |
Zero, lb/kg, Mode, Tare, Accum, Total, On/Off |
| Display |
LCD - 1” (25mm) |
LED - 1.5” (38mm) |
| Battery Life |
3,000 Hours |
500 Hours in LED |
| Batteries |
8 "D" Size disposable Alkaline dry cells or rechearable nicad cells (not included) |
| Accuracy |
+/- 0.1% of reading |
| Maximum Overload |
200% of capacity |
| Includes |
• Alkaline Batteries, • Top Eye Hook, • Bottom Swivel Hook, • Infrared Remote Control with Batteries |
Old Intercomp CS1500 Series Crane scales
| CS1500 Crane Scales |
| Model |
100661 |
100662 |
100663 |
100664 |
100665 |
100666 |
184508-RFX |
184509-RFX |
184510-RFX |
184511-RFX |
184512-RFX |
184513-RFX |
$1,434.95
|
$1,614.95
|
$1,614.95
|
- |
$1,794.95
|
$2,605.00
|
$1,795.50
|
$1,975.50
|
$1,975.50
|
$2,155.50
|
$2,395.00
|
$2,965.50
|
Capacity
Graduation |
500 x 0.2 lb
250 x 0.1 kg |
1000 x 0.5 lb
500 x 0.2 kg |
2000 x 1.0 lb
1000 x 0.5 kg |
5000 x 2.0 lb
2500 x 1.0 kg |
10,000 x 5.0 lb
5000 x 2 kg |
20,000 x 10 lb
10,000 x 5 kg |
500 x 0.2 lb
250 x 0.1 kg |
1000 x 0.5 lb
500 x 0.2 kg |
2000 x 1.0 lb
1000 x 0.5 kg |
5000 x 2.0 lb
2500 x 1.0 kg |
10,000 x 5.0 lb
5000 x 2 kg |
20,000 x 10 lb
10,000 x 5 kg |
| Legal For Trade |
NTEP #97-135A4 |
| Weight |
21 lb/10kg |
25 lb/12kg |
46 lb/20 kg |
88 lb/40kg |
22 lb/10kg |
38 lb/17kg |
45 lb/20 kg |
| General |
Zero, lb/kg On, Off, Tare, Print, Mode, Set |
| Display |
5 1/2 Digit, 0.8 Inch, 20 mm high LED Display |
| Indicator |
lb/kg, Gross, Net, Total and Peak Hold |
Intercomp 101225-RFX |
| Battery Life |
Standard Alkaline D-Cell Batteries Last up to 90 Hours in Scales |
| Batteries |
8 "D" Size disposable Alkaline dry cells or rechearable nicad cells (not included) |
| Resolution |
20 bit A/D delivers over 1,000,000 internal counts |
| Auto-Zero |
Satisfies all NIST/OIML requirements |
| Zero |
Up to 100% excluding NIST/OIML units |
| Humidity |
10 to 95% non-condensing |
| Temperature |
Operating -4o to 140oF/- 20o to 60oC |
| Filtering |
6-Pole, 10 Hertz low pass |
| Speed |
3 Seconds to typical reading |
| Accuracy |
+/- 0.1% of reading |
| Maximum Overload |
500% of capacity |
| Enclosure |
NEMA IV cast aluminum case |
| Hook or Eye |
Crosby-Laughlin or equivalent |
| USB/RS232 Output |
- |
YES |
| Options |
RS 232 Serial Output (sold separately)
LED Display (sold separately)
Direct 120/220 vold power supply (sold separately) |
Printer |

|
