Ishida IGX-300 Legal for Trade Checkweighing Bench Scale 300 x 0.1 lb |
|
| When the user defined upper limit is exceeded, the letter "H" is displayed. When the value is under the lower limit, "L" is displayed. An audible beep warns the operator that the item is out of tolerance. more ... |
|
Scales >
Industrial Scales >
Checkweighing
|
|
|
|
|
|
Features
Expand Your Range of Applications
Simple to Use Tare Function Place a container on the platform and press the Tare key. The tare is automatically stored in memory and the net weight is displayed during each subsequent weight.
Easy-to-Read Rotating Display Choose a large, bright VFD (IGX models) display or a vivid LCD (IGB models) display to meet your application needs and ease operator reliability. For optimum viewing, and to help eliminate errors, the indicator head can be vertically adjusted with the turn knobs.
Checkweighing Function Simplifies Control When the user defined upper limit is exceeded, the letter "H" is displayed. When the value is under the lower limit, "L" is displayed. An audible beep warns the operator that the item is out of tolerance.
Auto Power Off Function The IGB model features battery operation with a selectable automatic power-off function to extend battery life. For those applications where AC power is available, select either the IGB with optional AC adapter or IGX.
|
|
Other Ishida IGX Series Legal for Trade Checkweighing Bench Scale
|
Specifications
| Model Single Display |
IGX-150 |
IGX-300 |
IGB-150 |
IGB-300 |
| 84989 |
84990 |
84991 |
84992 |
Capacity
Readability |
150 x 0.05 lb
60 x 0.02 kg |
300 x 0.1 lb
150 x 0.05 kg |
150 x 0.5 lb
60 x 0.02 kg |
300 x 0.1 lb
150 x 0.05 kg |
| Legal For Trade |
NTEP CC 05-020, Class III, 3,000 d |
| Display |
vacuum fluorescent display (VFD), 25 mm |
liquid crystal display (LCD), 29 mm |
| Accuracy |
Configurable 1/3,000(Legal for Trade setting), 1/6,000, 1/7,500 |
| Display Items |
Weight: 5 digits, center of zero, tare, checkweighing: over “H”, under “L” |
| Power |
IGX: 120 V |
IGB: D size batteries or optional AC adapter (batteries not included) 500 hour battery life |
| Operating Temperature |
23º F to 109º F (-5º C to 40º C) |
| PLU |
10 PLUs for storing tare, upper limit, lower limit |
| Internal buzzer |
YES |
- |
| Platter Size |
(W x L): 15.75 x 21.65 |
|
|
|
|
|
|
| |
|
|
|
|
