Doran EXOPT205 Bluetooth Internal Transmitter & USB Receiver Includes one internal class 1 Bluetooth Transmitter and one class 1 Receiver USB Adapter

this option is Factory Installed and must be added with the scale

Doran EXOPT205 Bluetooth Internal Transmitter Includes one internal class 1 Bluetooth Transmitter

this option is Factory Installed and must be added with the scale

Doran EXOPT205 Bluetooth USB Receiver Includes one class 1 Receiver USB Adapter

Doran EXOPT101 Ethernet Wired - Includes Internal Ethernet interface board with sealed RJ45 connector on the back of the scale

this option is Factory Installed and must be added with the scale

Doran EXOPT150 Washdown Safe RJ45 Ethernet Connector Field Install Kit Includes one NEMA4X connerctor to mate to the connector on the back of the scale. Installes on customer supplied cable..

Requires a RJ45 cable crimping tool

Doran EXOPT102 Wireless Ethernet 802.11b - Includes Internal Ethernal interface board and a 3.5 Inch long flexable antenna with a NEMA4X bulkhead mount on the back of the meter.

this option is Factory Installed and must be added with the scale

Doran EXOPT160 USB Interface - Includes Internal USB interface board and a sealed USB Type A connector bulkhead mounted on the back of the meter with a NEMA 4X sealing cap. For scales used in wet environment choose one of the following USB Waterproof cables (IP67 and NEMA 4X Rated)

This Option can be combined with the 4-20mA Analog Output, Digital Output Board and internal Relay Options

this option is Factory Installed and must be added with the scale

Doran EXOPT100 4-20mA Analog Output Passive or Active - Includes 4-20mA interface board (12 Bit accuracy) & 12 feet of cable.

This Option can be combined with the RS-485 Serial Output, Digital Output Board, Internal Relay and USB Interface Options

this option is Factory Installed and must be added with the scale

Doran EXOPT186 Modbus/TCP - Includes Internal Modbus/TCP Interface board with a sealed RJ45 Connector bulkhead mounted on the back of the meter with a NEMA 4X IP67 sealing cap.

this option is Factory Installed and must be added with the scale

Doran EXOPT150 Washdown Safe RJ45 ModbusTCPConnector Field Install Kit Includes one NEMA4X connerctor to mate to the connector on the back of the scale. Installes on customer supplied cable..

Requires a RJ45 cable crimping tool

Doran EXOPT103 Fiber Optic Interface - Includes internal fiber optic interface board a special backplate and 50 feet () 15m) of fiber optic cable. This Option can be combined with the digital Outboard Option and Internal Relay Option

this option is Factory Installed and must be added with the scale

Doran EXOPT104 Digital Output Board - Includes Six feet of 12 conductor cable. Provides 8 open collector outputs.

this option is Factory Installed and must be added with the scale

Doran EXPOT106 Internal Relay Option - Includes Internal relay board with sockets to accept up to four relays. Also includes an attached six foot long cable with color-coded leads. Relays can be configured as normally open or closed

Note:
1. One or more of the folowing realys must be orderd with this option.
2. The digital output board option (part EXOPT104) is required unless the scale is equipped with wired ethernet, wired Ethernet, wireless Ethernet or RS485

this option is Factory Installed and must be added with the scale

Doran EXPOT107 External Relay Option - Includes 10 x 7 Inch housing with 5 vold power supply and DIN rail to accommodate up to 8 mechanical or solid state relays. Relays can be configured as normally open or closed. One or more of the following external must be ordered with the option

ECOPT196 , EXOPT112, EXOPT113

Doran EXOPT118 RS-232 Serial Output - 10 ft cable w Pigtail Ends

Serial data Output default settings are 6900 baud, 8 bits, no parity and one stop bit

RS-323 Options CAN NOT be orderd with the following options
RS485 serial OUTput (ECOPT105)
Ethernet - Wired EXOPT101
Ethernet - Wireless EXOPT102
Fiber Optic Interface EXOPT103
USB Interface EXOPT160
Bluetooth EXOPT205

Doran EXOPT119 RS-232 Serial Output - 10 ft cable 9 PIN FEMALE D connector - Scale to PC

Serial data Output default settings are 6900 baud, 8 bits, no parity and one stop bit

RS-323 Options CAN NOT be orderd with the following options
RS485 serial OUTput (ECOPT105)
Ethernet - Wired EXOPT101
Ethernet - Wireless EXOPT102
Fiber Optic Interface EXOPT103
USB Interface EXOPT160
Bluetooth EXOPT205

Doran EXOPT148 RS-232 Serial Output - 10 ft cable 9 PIN MALE D connector - Scale to Printer

Serial data Output default settings are 6900 baud, 8 bits, no parity and one stop bit

RS-323 Options CAN NOT be orderd with the following options
RS485 serial OUTput (ECOPT105)
Ethernet - Wired EXOPT101
Ethernet - Wireless EXOPT102
Fiber Optic Interface EXOPT103
USB Interface EXOPT160
Bluetooth EXOPT205

Doran EXOPT105 RS-485 Serial Output - 10 ft cable w Pigtail Ends

Serial data Output default settings are 6900 baud, 8 bits, no parity and one stop bit

RS-323 Options CAN NOT be orderd with the following options
RS485 serial OUTput (ECOPT105)
Ethernet - Wired EXOPT101
Ethernet - Wireless EXOPT102
Fiber Optic Interface EXOPT103
USB Interface EXOPT160
Bluetooth EXOPT205

Doran EXOPT124 230 VAC Operation for scales with an Internal Battery

Must be orderd with scale

Doran EXOPT147 6-24VDC Power - Incudes 2 pin in-line connector on a 6 Inch length of cable with the mating connector attached to a 21 Inch length of two conductor cable. Connectors have a washdown rating or IP68.

Must be orderd with scale

Doran EXOPT151 Internal Audible Alarm Option Accept - Chime - 1, 2, or 3 audible alarms For “Over”, “Accept”, or “Under”, varying tones and volume control - specify beepers at time of order (3 maximum). Alarms are rated NEMA 4X.

Must be orderd with scale

Doran EXOPT152 Internal Audible Alarm Option Over - Continous- 1, 2, or 3 audible alarms For “Over”, “Accept”, or “Under”, varying tones and volume control - specify beepers at time of order (3 maximum). Alarms are rated NEMA 4X.

Must be orderd with scale

Doran EXOPT152 Internal Audible Alarm Option Under - Warble- 1, 2, or 3 audible alarms For “Over”, “Accept”, or “Under”, varying tones and volume control - specify beepers at time of order (3 maximum). Alarms are rated NEMA 4X.

Must be orderd with scale

Doran EXOPT157 External Audible Alarm Option Accept - Chime - 1, 2, or 3 audible alarms For “Over”, “Accept”, or “Under”, varying tones and volume control - specify beepers at time of order (3 maximum). Alarms are rated NEMA 4X and are mouted in a NEMA 4X Rated plastic enclosure (5" w x 4" h x 2" d) with 10 feet of cable..

Must be orderd with scale

Doran EXOPT157 External Audible Alarm Option Accept - Chime - 1, 2, or 3 audible alarms For “Over”, “Accept”, or “Under”, varying tones and volume control - specify beepers at time of order (3 maximum). Alarms are rated NEMA 4X and are mouted in a NEMA 4X Rated plastic enclosure (5" w x 4" h x 2" d) with 10 feet of cable..

Must be orderd with scale

Doran EXOPT157 External Audible Alarm Option Accept - Chime - 1, 2, or 3 audible alarms For “Over”, “Accept”, or “Under”, varying tones and volume control - specify beepers at time of order (3 maximum). Alarms are rated NEMA 4X and are mouted in a NEMA 4X Rated plastic enclosure (5" w x 4" h x 2" d) with 10 feet of cable..

Must be orderd with scale

Doran EXOPT115 Remote Switch Configured for remote ZERO standard painted steel 3-1/2" x 2-5/8" x 1" includes a 10 foot Cable

Doran EXOPT115 Remote Switch Configured for remote PRINT standard painted steel 3-1/2" x 2-5/8" x 1" includes a 10 foot Cable

Doran EXOPT117 Remote Switch Configured for remote UNITS standard painted steel 3-1/2" x 2-5/8" x 1" includes a 10 foot Cable

Doran EXOPT165 Remote Switch Washdown Configured for remote ZERO washdown safe IP68 4"x 3-7/16" x 1-5/32" includes a 10 foot Cable

Doran EXOPT165 Remote Switch Washdown Configured for remote ZERO washdown safe IP68 4"x 3-7/16" x 1-5/32" includes a 10 foot Cable

Doran EXOPT165 Remote Switch Washdown Configured for remote ZERO washdown safe IP68 4"x 3-7/16" x 1-5/32" includes a 10 foot Cable

The Doran LR350 barcode label printer offers outstanding performance, reliability and flexibility to meet the demands of todays fast paced label printing applications. Ideal for all non-washdown applications such as: packaging, production, warehousing, shipping and receiving printing needs.

Direct thermal print technology provides high quality labels time after time. Preloaded Doran label formats provide true plug and play setup for most labeling applications - custom label designs are also available.

• Direct Thermal 203 dpi Resolution
• 68" Maximum Print Length
• 4.25" Maximum Print Width
• Compatible with "Create a Label" for easy label design
• Includes one roll of 4" x 5" labels
• Label Gap Sensor
• USB 2.0 PC Interface (drivers included)
• RS-232 Scale Interface
• 2 MB User Storage
• Heavy Duty ABS construction, suitable for Non-washdown applications
• Windows PC for label design (Programmable via USB Port)
• Optional Label Peeler

Doran Scale to be Used With the Printer: PC400, PC500, 4300, 7000XL, 7400, 8000XL, 2200, 2200B, 2200CW
