Intercomp CS1500 Series Crane scale
With large, easy-to-read LCD or LED displays, CS1500™ high performance crane scales are available in a range of capacities from 500lb (250kg) to 20,000lb (10,000kg), are NTEP certified, and boast best-in-class battery life.
Intercomp CS1500 100661 Crane Scale with remote, 500 x 0.2 Ib
With LCD Display
Intercomp CS1500 100661 Crane Scale with remote, 500 x 0.2 Ib
With LED Display

Specifications Chart

View Old Models

Intercomp offers the industry’s most extensive line of crane scales, and can provide your company with a cost-effective solution to virtually every overhead industrial weighing application - ranging from 25 to 600,000 lbs/ 12.5 to 300,000 kg.

Our advanced design, value-packed with the industry’s most desired features, makes Intercomp the first choice over other electronic units. Ultra high-resolution, A/D conversion delivers unsurpassed accuracy, and digital keypad setup and calibration enhance the ease of operation.

Legal For Trade

All crane unit electronics are shock-mounted in a weatherproof case and provide maximum protection against moisture, dust and rough usage. Features include a high-visibility digital readout for easy reading of weights and large pushbutton switches for simple, trouble-free operation.

Low-cost, high performance digital crane scale for medium capacity industrial applications. The unique design flexibility lets you choose the model and weighing capacity you need - NTEP certified from 300 to 20,000 lb/150 to 10,000 kg. The unit utilizes a high-visibility 0.8 inch/20 mm LED digital readout and the efficient micro-controller delivers up to 100 hours of operation on eight (8) D-cell batteries. Crosby eye hook and bottom swivel hook.

With large, easy-to-read LCD or LED displays, CS1500™ high performance crane scales are available in a range of capacities from 500lb (250kg) to 20,000lb (10,000kg), are NTEP certified, and boast best-in-class battery life. Both models come standard with RFX™ Wireless Weighing Technology enabling cable-free control and monitoring of scales. They also feature an optional USB/RS232 output, multi-scale communication, and a multitude of remote display options

Intercomp CS1500-RFX Series
Crane Scales

Model


Intercomp 184507 RS232/DIRECT POWER OPTION RFX CRANE SCALES (MUST BE ORDERED WITH SCALE), add $49.00

Intercomp Part 101231, Cable, to Thermal Printer, 15 ft., add $145.00

Intercomp Part 330112-CS Battery Pack qty. 2 x 4 D-size NiCad for Intercomp CS1500, CS3000 & CS5000, add $216.00

Intercomp Part 100858 Charger,External,120/220 V, for qty. 2x4 D-NiCad/NiMH for Intercomp CS1500, CS3000 & CS5000, add $279.00

Intercomp Part 101055 Direct Power 120V w/NiCad batteries for Intercomp CS1500, CS3000 & CS5000, add $345.00

Intercomp Part 101233, Cable, RS232/USB output, 15 ft., add $145.00
Intercomp 100015 RFX™ Wireless S400™ Indoor Numeric Remote Display
Intercomp 100015 RFX™ Wireless S400™ Indoor Numeric Remote Display
Price: $1,790.00
In Stock
btn buy
Intercomp 100016-RFX  RFX™ Wireless S400HI™ Outdoor Numeric Remote Display
Intercomp 100016-RFX RFX™ Wireless S400HI™ Outdoor Numeric Remote Display
Price: $2,090.00
In Stock
btn buy
Intercomp Part 340105-RFX Wireless Thermal Printer with RFX™ Communication Module
Intercomp Part 340105-RFX Wireless Thermal Printer with RFX™ Communication Module
Price: $981.00
In Stock
btn buy
Intercomp 101221-RFX  PT20 CPU RFX Indicator with Built-in-Printer
Intercomp 101221-RFX PT20 CPU RFX Indicator with Built-in-Printer
Price: $2,995.00
In Stock
btn buy
Intercomp 101225-RFX Handheld Weighing RFX Indicator
Intercomp 101225-RFX Handheld Weighing RFX Indicator
Price: $895.50
In Stock
btn buy
Intercomp 140759  IntercompWeigh™ Software
Intercomp 140759 IntercompWeigh™ Software
Price: $995.00
In Stock
btn buy
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
Price: $995.00
In Stock
btn buy

CS1500 Crane Scales
Model 184500-RFX 184501-RFX 184502-RFX 184503-RFX 184504-RFX 184505-RFX 184514-RFX 184515-RFX 184516-RFX 184517-RFX 184518-RFX 184519-RFX
Price Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,525.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,705.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,705.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,885.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,885.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$2,695.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,435.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,525.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,525.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,795.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,795.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$2,605.50
buy now
Capacity
Graduation
500 x 0.2 lb
250 x 0.1 kg
1000 x 0.5 lb
500 x 0.2 kg
2000 x 1.0 lb
1000 x 0.5 kg
5000 x 2.0 lb
2500 x 1.0 kg
10,000 x 5.0 lb
5000 x 2 kg
20,000 x 10 lb
10,000 x 5 kg
500 x 0.2 lb
250 x 0.1 kg
1000 x 0.5 lb
500 x 0.2 kg
2000 x 1.0 lb
1000 x 0.5 kg
5000 x 2.0 lb
2500 x 1.0 kg
10,000 x 5.0 lb
5000 x 2 kg
20,000 x 10 lb
10,000 x 5 kg
Legal For Trade NTEP #97-135A4
Protection IP65
Weight 29 lb/13 kg 50 lb/23 kg 91 lb/41 kg 21 lb/10 kg 25 lb/12 kg 46 lb/20 kg 88 lb/40 kg
General Zero, lb/kg, Mode, Tare, Accum, Total, On/Off
Display LCD - 1” (25mm) LED - 1.5” (38mm)
Battery Life 3,000 Hours 500 Hours in LED
Batteries 8 "D" Size disposable Alkaline dry cells or rechearable nicad cells (not included)
Accuracy +/- 0.1% of reading
Maximum Overload 200% of capacity
Includes • Alkaline Batteries, • Top Eye Hook, • Bottom Swivel Hook, • Infrared Remote Control with Batteries








Old Intercomp CS1500 Series Crane scales

CS1500 Crane Scales
Model 100661 100662 100663 100664 100665 100666 184508-RFX 184509-RFX 184510-RFX 184511-RFX 184512-RFX 184513-RFX
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,434.95
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,614.95
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,614.95
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,794.95
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,794.95
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$2,605.00
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,795.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,975.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$1,975.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$2,155.50
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$2,395.00
buy now
Intercomp 189006 RFX TO WIFI CONVERTER MODULE for iVehicleWeigh or iExactWeigh
$2,965.50
buy now
Capacity
Graduation
500 x 0.2 lb
250 x 0.1 kg
1000 x 0.5 lb
500 x 0.2 kg
2000 x 1.0 lb
1000 x 0.5 kg
5000 x 2.0 lb
2500 x 1.0 kg
10,000 x 5.0 lb
5000 x 2 kg
20,000 x 10 lb
10,000 x 5 kg
500 x 0.2 lb
250 x 0.1 kg
1000 x 0.5 lb
500 x 0.2 kg
2000 x 1.0 lb
1000 x 0.5 kg
5000 x 2.0 lb
2500 x 1.0 kg
10,000 x 5.0 lb
5000 x 2 kg
20,000 x 10 lb
10,000 x 5 kg
Legal For Trade NTEP #97-135A4
Weight 21 lb/10kg 25 lb/12kg 46 lb/20 kg 88 lb/40kg 22 lb/10kg 38 lb/17kg 45 lb/20 kg
General Zero, lb/kg On, Off, Tare, Print, Mode, Set
Display 5 1/2 Digit, 0.8 Inch, 20 mm high LED Display
Indicator lb/kg, Gross, Net, Total and Peak Hold Intercomp 101225-RFX
Battery Life Standard Alkaline D-Cell Batteries Last up to 90 Hours in Scales
Batteries 8 "D" Size disposable Alkaline dry cells or rechearable nicad cells (not included)
Resolution 20 bit A/D delivers over 1,000,000 internal counts
Auto-Zero Satisfies all NIST/OIML requirements
Zero Up to 100% excluding NIST/OIML units
Humidity 10 to 95% non-condensing
Temperature Operating -4° to 140°F/- 20° to 60°C
Filtering 6-Pole, 10 Hertz low pass
Speed 3 Seconds to typical reading
Accuracy +/- 0.1% of reading
Maximum Overload 500% of capacity
Enclosure NEMA IV cast aluminum case
Hook or Eye Crosby-Laughlin or equivalent
USB/RS232 Output - YES
Options RS 232 Serial Output (sold separately)
LED Display (sold separately)
Direct 120/220 vold power supply (sold separately)
Printer
